YASKAWA SGM-A3

SERVO SELECTION AND DATA SHEETS
5.1.2 Selecting a Servopack cont.
214
2) The actual selection of the DR2 Servopack is conducted according to the following flow-
chart.
DR2-JJ__
DR2-jjA_
DR2-jjB_
Start Servopack selection
1) Enter rated output
Check specifications in
5.3.1 Ratings
and Specifications.
D Enter a rated output equal
to the motor capacity.
Enter rated output
Enter code as characters 1 and 2:
30W (0.04HP) = A3, 50W (0.07HP) = A5,
100W (0.13HP) = 01, 200W (0.27HP) = 02,
300W (0.40HP) = 03, 400W (0.53HP) = 04,
750W (1.01HP) = 08
2) Determine supply voltage
200 V power supply
100 V power supply
3) Select model
DDD
100 V / 200 V ?
Flowchart for Servopack Selection
Always enter C.
DR2-jjjC
DR2-jjjj
DR2-jjjjP
4) Determine applicable motor
The applicable motor type (SGM/SGMP) can be changed
by setting of the user constants.
Type SGM
Type SGMP
Type SGM /
Type SGMP
?
To the next page.
5
