SERVO SELECTION AND DATA SHEETS
5.2.1 Ratings and Specifications cont.
220
3) 200-VAC SGM Servomotor Torque-Motor Speed Characteristics
• SGM-A3A (V) • SGM-A5A (V)
• SGM-01A (V) • SGM-02A (V)
• SGM-04A (V) • SGM-08A (V)
Motor
Speed
(r/min)
Motor
Speed
(r/min)
Motor
Speed
(r/min)
Motor
Speed
(r/min)
Motor
Speed
(r/min)
Motor
Speed
(r/min)
4000
3000
2000
1000
0
0 0.1 0.2 0.3 0.4
0204060
4000
3000
2000
1000
0
0 0.15 0.3 0.45 0.6
0 20 40 60 80 100
4000
3000
2000
1000
0
0 0.25 0.5 0.75 1
0 50 100 150
4000
3000
2000
1000
0
0 0.5 1 1.5 2
0 100 200 300
4000
3000
2000
1000
0
0123 4
0 200 400 600
4000
3000
2000
1000
0
02468
0 400 800 1200
A: Continuous Duty Zone
B: Intermittent Duty Zone
