Pn50D
Input Signal Selection 4 0000 to FFFF − 8888 After restart Setup −
Pn50E
Output Signal Selection 1 0000 to 3333 − 3211 After restart Setup −
Parameter
No.
Name
Setting
Range
Units
Factory
Setting
When
Enabled
Classification
Reference
Section
4th
digit
3rd
digit
2nd
digit
1st
digit
n.
0 to F Same as /ZCLAMP
/G-SEL1 Signal Mapping (Gain change when ON (L-level)) (Refer to 6.8.6.)
/ZCLAMP Signal Mapping (Zero clamp when ON (L-level)) (Refer to 5.3.5.)
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0 to F Same as /ZCLAMP
/INHIBIT Signal Mapping (Reference pulse inhibit when ON (L-level)) (Refer to 5.4.7.)
Reserved (Do not change.)
ON when CN1-40 input signal is ON (L-level).
ON when CN1-41 input signal is ON (L-level).
ON when CN1-42 input signal is ON (L-level).
ON when CN1-43 input signal is ON (L-level).
ON when CN1-44 input signal is ON (L-level).
ON when CN1-45 input signal is ON (L-level).
ON when CN1-46 input signal is ON (L-level).
Sets signal ON.
Sets signal OFF.
ON when CN1-40 input signal is OFF (H-level).
ON when CN1-41 input signal is OFF (H-level).
ON when CN1-42 input signal is OFF (H-level).
ON when CN1-43 input signal is OFF (H-level).
ON when CN1-44 input signal is OFF (H-level).
ON when CN1-45 input signal is OFF (H-level).
ON when CN1-46 input signal is OFF (H-level).
4th
digit
3rd
digit
2nd
digit
1st
digit
n.
0 to 3 Same as /COIN
Servomotor Rotation Detection Signal Mapping (/TGON) (Refer to 5.10.3.)
Positioning Completion Signal Mapping (/COIN) (Refer to 5.4.5.)
0
1
2
3
0 to 3 Same as /COIN
Speed Coincidence Detection Signal Mapping (/V-CMP) (Refer to 5.3.8.)
0 to 3 Same as /COIN
Servo Ready Signal Mapping (/S-RDY) (Refer to 5.10.4.)
Disabled (the above signal is not used.)
Outputs the signal from CN1-25, 26 output terminal.
Outputs the signal from CN1-27, 28 output terminal.
Outputs the signal from CN1-29, 30 output terminal.
