11 Appendix
11.2.2 Parameters
11-26
Pn50F
Output Signal Selection 2 0000 to 3333 − 0000 After restart Setup −
Pn510
Output Signal Selection 3 0000 to 0033 − 0000 After restart Setup −
Pn511
Reserved 0000 to FFFF − 8888 After restart Setup −
Parameter
No.
Name
Setting
Range
Units
Factory
Setting
When
Enabled
Classification
Reference
Section
4th
digit
3rd
digit
2nd
digit
1st
digit
n.
0 to 3 Same as /CLT
Brake Signal Mapping (/BK) (Refer to 5.2.4.)
Torque Limit Detection Signal Mapping (/CLT) (Refer to 5.8.5.)
0
1
2
3
0 to 3 Same as /CLT
Speed Limit Detection Signal Mapping (/VLT) (Refer to 5.5.3.)
0 to 3 Same as /CLT
Warning Signal Mapping (/WARN) (Refer to 5.10.2.)
Disabled (the above signal is not used.)
Outputs the signal from CN1-25, -26 output terminal.
Outputs the signal from CN1-27, -28 output terminal.
Outputs the signal from CN1-29, -30 output terminal.
(Refer to 5.8.5)
(Refer to 5.5.4)
(Refer to 5.2.4)
(Refer to 5.10.2)
4th
digit
3rd
digit
2nd
digit
1st
digit
n.
Near Signal Mapping (/NEAR) (Refer to 5.4.6.)
0
1
2
3
Reserved (Do not change.)
Disabled (the above signal is not used.)
Outputs the signal from CN1-25, -26 terminal.
Outputs the signal from CN1-27, -28 terminal.
Outputs the signal from CN1-29, -30 terminal.
Reserved (Do not change.)
Reserved (Do not change.)
(Refer to 5.4.6)
4th
digit
3rd
digit
2nd
digit
1st
digit
n.
Reserved (Do not change.)
Reserved (Do not change.)
Reserved (Do not change.)
Reserved (Do not change.)
