4.5 Trial Operation of Servomotor with Brakes
4-11
4
Trial Operation
4.5 Trial Operation of Servomotor with Brakes
Observe the following precautions when performing a trial operation of servomotor with brake.
When checking the brake operation, take advance measures to prevent vibration due to gravity acting on the
machine or external forces.
Check the servomotor operation and holding brake operation with the servomotor separated from the
machine. If both operations are correct, connect the servomotor to the machine and perform trial operation.
Holding brake operation of the servomotor with brake can be controlled with the brake signal (/BK) of the
SERVOPACK.
For wiring on a servomotor with brakes and setting parameters, refer to 5.2.4 Holding Brakes.
5
Perform trial operation with the servomotor connected to the machine, following
each section in 4.3 Trial Operation for Servomotor without Load from Host Refer-
ence.
Check that the trial operation is completed with as the trial operation for servomotor
without load. Also check the settings for machine such as reference unit.
4.3 Trial Operation for
Servomotor without Load
from Host Reference
6
Check the settings of parameters for control method used set in step 2 again.
Check that the servomotor rotates matching the machine operating specifications.
7
Adjust the servo gain and improve the servomotor response characteristics, if neces-
sary.
6 Adjustments
8
Write the parameters set for maintenance in 11.4 Parameter Recording Table.
Then the trial operation with the servomotor connected to the machine is completed.
Note: If the optional digital operator is used, parameters can be saved. SigmaWin+,
which is a tool for supporting the servo drive, can then manage the saved
parameters in files.
11.4 Parameter Record-
ing Table
(cont’d)
Step Operation Reference
Note: The servomotor will not be broken in completely during the trial operation.
Therefore, let the system run for a sufficient amount of additional time to
ensure that it is properly broken in.
Failures caused by incorrect wiring or wrong voltage application in the brake circuit may
damage the equipment or cause an accident resulting in death or injury. Follow the pro-
cedures and instructions for wiring and trial operation precisely as described in this man-
ual.
