1.4 Ratings and Specifications
This section describes the ratings and specifications of SERVOPACKs and converters.
1.4.1 Ratings
Ratings of SERVOPACKs and converters are as shown below.
Three-phase 200 VAC
∗ Refer to 3.7 Selecting and Connecting a Regenerative Resistor Unit for details.
Three-phase 400 VAC
∗ Refer to 3.7 Selecting and Connecting a Regenerative Resistor Unit for details.
SERVOPACK Model SGDV- 121H 161H 201H
Converter Model SGDV-COA 2BAA 3GAA 3GAA
Continuous Output Current [Arms] 116 160 200
Instantaneous Max. Output Current [Arms] 240 340 460
Regenerative Resistor Unit
* External
Main Circuit Power Supply Three-phase 200 to 230 VAC, +10% to -15%, 50/60 Hz
Control Power Supply Single-phase 200 to 230 VAC, +10% to -15%, 50/60 Hz
Overvoltage Category III
SERVOPACK Model SGDV- 750J 101J 131J
Converter Model SGDV-COA 3ZDA 5EDA 5EDA
Continuous Output Current [Arms] 75 98 130
Instantaneous Max. Output Current [Arms] 170 230 340
Regenerative Resistor Unit
*
External
Main Circuit Power Supply Three-phase 380 to 480 VAC, +10% to -15%, 50/60 Hz
Control Power Supply 24 VDC, ±15%
Overvoltage Category III
