1.4 Ratings and Specifications
1-9
∗1. Speed regulation by load regulation is defined as follows:
∗2. Set Pn001 to n.2 if you do not use the dynamic brake.
∗3. Refer to 3.8 Selecting and Connecting a Dynamic Brake Unit for details on dynamic brake units.
∗4. Refer to 3.7 Selecting and Connecting a Regenerative Resistor Unit for details on regenerative resistor unit.
∗5. Implement risk assessment and confirm that the safety requirements of the machine have been met.
Dynamic Brake (DB)
*2
Included
An external dynamic brake unit is required.
*3
Regenerative Processing
Included
An external regenerative resistor unit is required.
*4
Overtravel Prevention (OT)
Dynamic brake stop, deceleration to a stop, or free run to a stop at P-OT or
N-OT
Protective Function
Overcurrent, overvoltage, insufficient voltage, overload, regeneration error,
and so on.
Utility Function Gain adjustment, alarm history, JOG operation, origin search, and so on.
Safety Function
Input /HWBB1, /HWBB2: Baseblock signal for power module
Output EDM1: Monitoring status of internal safety circuit (fixed output)
Standards
*5
(Application
pending)
EN 954 Category 3, IEC 61508 SIL2
Optional Module Fully-closed module, safety module
(cont’d)
Speed regulation =
No-load motor speed Total load motor speed
Rated motor
speed
×
100%
-
To Next Page
