Page #422 background imageLoading...
Page #422 background image
11 Appendix
11.2.2 Parameters
11-34
∗1. Normally set to "0." When using an external regenerative resistor, set the capacity (W) of the regenerative resistor
unit.
∗2. The upper limit is the maximum output capacity (W) of the SERVOPACK.
∗3. These parameters can be set in SERVOPACKs with safety modules. For details, refer to
Σ
-V Series Users Manual,
Safety Module (No.: SIEP C720829 06).
Pn551 2 Analog Monitor 2 Offset Voltage
-10000 to
10000
0.1 V 0 Immediately Setup 6.1.3
Pn552 2
Analog Monitor
Magnification (×1)
-10000 to
10000
×0.01 100 Immediately Setup 6.1.3
Pn553 2
Analog Monitor
Magnification (×2)
-10000 to
10000
×0.01 100 Immediately Setup 6.1.3
Pn560 2
Remained Vibration
Detection Width
1 to 3000 0.1% 400 Immediately Setup 6.7.1
Pn561 2 Overshoot Detection Level 0 to 100 1% 100 Immediately Setup
6.3.1
6.4.1
Pn600 2
Regenerative Resistor Capacity
1
Depends on
SERVOPACK
Capacity
2
10 W 0 Immediately Setup 3.7.3
Pn601 2 Dynamic brake resistor capacity
0 or higher
(Max. value
depends on
model.)
2
10 W 0 Immediately Setup 3.8.2
Pn621 to
Pn628
*3
SERVOPACK: Safety Module
Parameters
––
(cont’d)
Parameter
No.
Size
Name
Setting
Range
Units
Factory
Setting
When Enabled
Classifi-
cation
Reference
Section
