3 Wiring and Connection
3.2.2 Interconnecting Terminals
3-22
(2) SGDV-COA3GAA, -COA5EDA Converters
The busbars can be connected in any direction.
Converter’s P terminal
Converter’s N terminal
SERVOPACK’s P terminal
SERVOPACK’s N terminal
Analog
Analog
