YASKAWA V1000

Table C.1 EN 61800-3 Category C1 Filters
Drive
CIMR-Vo
Filter Data (Manufacturer: Schaffner)
Type
Rated
Current
(A)
Weight
(lb)
Dimensions
[W x L x H] (in)
Mounting
Dimensions
[Y x X] (in)
Drive
Mounting
Screw A
Filter
Mounting
Screw
200 V Single-Phase Units
BA0001 FS23638-10-07 10 0.97 2.8 x 6.7 x 1.8 2.0 x 6.1 M4 M5
BA0002 FS23638-10-07 10 0.97 2.8 x 6.7 x 1.8 2.0 x 6.1 M4 M5
BA0003 FS23638-10-07 10 0.97 2.8 x 6.7 x 1.8 2.0 x 6.1 M4 M5
BA0006 FS23638-20-07 20 1.65 4.4 x 6.7 x 2.0 3.6 x 6.1 M4 M5
BA0010 FS23638-20-07 20 1.65 4.4 x 6.7 x 2.0 3.6 x 6.1 M4 M5
BA0012 FS23638-30-07 30 2.42 5.7 x 6.9 x 2.0 4.7 x 6.3 M4 M5
BA0018 FS23638-40-07 40 2.87 6.9 x 6.9 x 2.0 5.9 x 6.3 M4 M5
200 V Three-Phase Units
2A0001 FS23637-8-07 7.3 0.88 2.8 x 6.7 x 1.6 2.0 x 6.1 M4 M5
2A0002 FS23637-8-07 7.3 0.88 2.8 x 6.7 x 1.6 2.0 x 6.1 M4 M5
2A0004 FS23637-8-07 7.3 0.88 2.8 x 6.7 x 1.6 2.0 x 6.1 M4 M5
2A0006 FS23637-8-07 7.3 0.88 2.8 x 6.7 x 1.6 2.0 x 6.1 M4 M5
2A0010 FS23637-14-07 14 1.28 4.4 x 6.7 x 1.8 3.6 x 6.1 M4 M5
2A0012 FS23637-14-07 14 1.28 4.4 x 6.7 x 1.8 3.6 x 6.1 M4 M5
2A0020 FS23637-24-07 24 1.98 5.7 x 6.9 x 2.0 4.7 x 6.1 M4 M5
2A0030 FS23637-52-07 52 4.41 5.4 x 12.0 x 2.2 3.9 x 11.4 M5 M5
2A0040 FS23637-52-07 52 4.41 5.4 x 12.0 x 2.2 3.9 x 11.4 M5 M5
2A0056 FS23637-68-07 68 5.73 6.9 x 13.4 x 2.6 5.1 x 12.8 M5 M6
2A0069 FS23637-80-07 80 6.83 8.3 x 15.5 x 2.6 6.6 x 14.9 M6 M8
400 V Three-Phase Units
4A0001 FS23639-5-07 5 1.10 4.4 x 6.7 x 1.8 3.6 x 6.1 M4 M5
4A0002 FS23639-5-07 5 1.10 4.4 x 6.7 x 1.8 3.6 x 6.1 M4 M5
4A0004 FS23639-5-07 5 1.10 4.4 x 6.7 x 1.8 3.6 x 6.1 M4 M5
4A0005 FS23639-10-07 10 1.54 4.4 x 6.7 x 1.8 3.6 x 6.1 M4 M5
4A0007 FS23639-10-07 10 1.54 4.4 x 6.7 x 1.8 3.6 x 6.1 M4 M5
4A0009 FS23639-10-07 10 1.54 4.4 x 6.7 x 1.8 3.6 x 6.1 M4 M5
4A0011 FS23639-15-07 15 1.98 5.7 x 6.9 x 2.0 4.7 x 6.3 M4 M5
4A0018 FS23639-30-07 30 4.0 5.4 x 12.0 x 2.2 3.9 x 11.4 M5 M5
4A0023 FS23639-30-07 30 4.0 5.4 x 12.0 x 2.2 3.9 x 11.4 M5 M5
4A0031 FS23639-50-07 50 6.0 6.9 x 13.4 x 2.6 5.1 x 12.8 M5 M6
C.1 European Standards
208
YASKAWA ELECTRIC TOEP C710606 47A YASKAWA AC Drive – V1000 Quick Start Guide
