Administrator’s Guide for SIP-T2_Series_T4_Series IP Phones
314
BLF LED Mode
BLF LED Mode provides four kinds of definition for the BLF key LED status. As there is no
hard line key on SIP-T48G IP phones, BLF LED mode configuration is only applicable to
SIP-T46G/T42G/T41P/T29G/T27P/T23P/T23G/T21(P) E2 IP phones. BLF LED mode is also
applicable to the expansion module EXP40 connected to SIP-T48G/T46G IP phones,
EXP39 connected to SIP-T29G and SIP-T27P IP phones. The following table lists the LED
statuses of the BLF key when BLF LED Mode is set to 0, 1, 2 or 3 respectively. The default
value of BLF LED mode is 0.
BLF LED mode feature is also applicable to BLF list key. For more information on BLF List
key, refer to BLF List on page 322.
Line key/Expansion Module Key LED (configured as a BLF key or a BLF List key and BLF
LED Mode is set to 0)
The monitored user is idle.
Fast flashing red (200ms)
The monitored user receives an incoming call.
The monitored user is dialing.
The monitored user is talking.
The monitored user’s conversation is placed on hold
(This LED status requires server support).
The call is parked against the monitored user’s phone
number.
The monitored user does not exist.
Line Key/Expansion Module Key LED (configured as a BLF key or a BLF List key and BLF
LED Mode is set to 1)
Fast flashing red (200ms)
The monitored user receives an incoming call.
The monitored user is dialing.
The monitored user is talking.
The monitored user’s conversation is placed on hold
(This LED status requires server support).
The call is parked against the monitored user’s phone
number.
The monitored user is idle.
The monitored user does not exist.
