Yealink T29G Administrator's Guide

Administrator’s Guide for SIP-T2_Series_T4_Series IP Phones
356
URL Record
When a user presses a URL record key for the first time during a call, the IP phone sends
an HTTP GET message to the server.
Example of an HTTP GET message:
GET /URLRecord/record.xml HTTP/1.1\r\n
Request Method: GET
Request URI: /URLRecord/record.xml
Request version: HTTP/1.1
Host: 10.3.5.97:8080\r\n
User-agent: Yealink SIP-T23G 44.80.0.20 00:15:65:74:B1:50\r\n
If the recording is successfully started, the server will respond with a 200 OK message.
Example of a 200 OK message:
<YealinkIPPhoneText>
<Title>
</Title>
<Text>
The recording session is successfully started.
</Text>
<YealinkIPPhoneText>
If the recording fails for some reasons, for example, the recording box is full, the server
will respond with a 200 OK message.
Example of a 200 OK message:
<YealinkIPPhoneText>
<Title>
</Title>
<Text>
Probably the recording box is full.
</Text>
<YealinkIPPhoneText>
When the user presses the URL record key for the second time, the IP phone sends an
HTTP GET message to the server, and then the server will respond with a 200 OK
message.
Example of a 200 OK message:
<YealinkIPPhoneText>
<Title>
</Title>
<Text>
The recording session is successfully stopped.

Yealink T29G Specifications

General

VoIP Protocols	SIP
PoE Support	Yes (IEEE 802.3af)
Headset Port	RJ9
Bluetooth	No
Weight	1.04 kg
Display	4.3" color display with backlight, 480 x 272 pixels
Line Keys	10 line keys
Ethernet Ports	2 x 10/100/1000 Mbps
Audio Codecs	G.722, G.711, G.729, G.726, iLBC
USB Port	1 x USB 2.0
Expansion Module Support	Yes, supports up to 6 EXP20 expansion modules
EHS	Yes
Supported Protocols	SIP
Operating Temperature	-10~50°C
Humidity	10% to 95% (non-condensing)
