Configuring Advanced Features
413
3. Enter the desired time interval in the Packet Interval (1~3600s) field.
4. Click Confirm to accept the change.
A dialog box pops up to prompt that settings will take effect after a reboot.
5. Click OK to reboot the phone.
To configure CDP feature via phone user interface:
1. Press Menu->Settings->Advanced Settings (default password: admin)
->Network->CDP->CDP Status.
2. Press or , or the Switch soft key to select the desired value from the CDP
Status field.
3. Enter the priority value (1-3600s) in the CDP Interval field.
4. Press the Save soft key to accept the change.
The IP phone reboots automatically to make settings effective after a period of time.
VLAN (Virtual Local Area Network) is used to logically divide a physical network into
several broadcast domains. VLAN membership can be configured through software
instead of physically relocating devices or connections. Grouping devices with a
common set of requirements regardless of their physical location can greatly simplify
network design. VLANs can address issues such as scalability, security and network
management.
The purpose of VLAN configurations on the IP phone is to insert tag with VLAN
information to the packets generated by the IP phone. When VLAN is properly
configured for the ports (Internet port and PC port) on the IP phone, the IP phone will tag
all packets from these ports with the VLAN ID. The switch receives and forwards the
