Yealink T29G Administrator's Guide

Administrator’s Guide for SIP-T2_Series_T4_Series IP Phones
20
For SIP-T23P/T23G/T21(P) E2:
3) Connect the network and power:
 AC power (Optional)
 Power over Ethernet (PoE)
Note
AC Power (Optional)
To connect the AC power and network:
1. Connect the DC plug of the power adapter to the DC5V port on the IP phone and
connect the other end of the power adapter into an electrical power outlet.
2. Connect the included or a standard Ethernet cable between the Internet port on
the IP phone and the one on the wall or switch/hub device port.
Power over Ethernet
With the included or a regular Ethernet cable, IP phones can be powered from a
PoE-compliant switch or hub.
PoE is not applicable to the SIP-T21 E2 IP phones.

Yealink T29G Specifications

General

VoIP Protocols	SIP
PoE Support	Yes (IEEE 802.3af)
Headset Port	RJ9
Bluetooth	No
Weight	1.04 kg
Display	4.3" color display with backlight, 480 x 272 pixels
Line Keys	10 line keys
Ethernet Ports	2 x 10/100/1000 Mbps
Audio Codecs	G.722, G.711, G.729, G.726, iLBC
USB Port	1 x USB 2.0
Expansion Module Support	Yes, supports up to 6 EXP20 expansion modules
EHS	Yes
Supported Protocols	SIP
Operating Temperature	-10~50°C
Humidity	10% to 95% (non-condensing)
