7-11
IM 04P01B01-01E
Setup Operations for Changing/Adding Functions (Basic Setting Mode)
7
Applying the Changes and Returning to Operation Mode
Press the key or SHIFT + key to select End and then press the key. Press
the
key to select Store and then press the key. The changes are applied, and
the screen returns to Operation mode. If you select Abort and press the
key, the
changes are discarded, and the screen returns to Operation mode. Press the ESC key to
return to the Basic= screen.
Explanation
CH/Tag
Channel: Prints the channel number.
Tag: Prints the tag.
Channel (Dot Model)
When On is selected channel number or tag is printed by the trend recording.
Alarm
On1: Prints the alarm information when an alarm occurs or releases.
On2: Prints the alarm information only when an alarm occurs.
Off: Does not print alarm information.
Pen Color Printout (Pen Model)
When On is selected, the recording color of the channel whose scale is printed is printed.
This is valid when the scale printout is turned On.
Note
Channel, alarm, recording start, and new chart speed printouts are not performed when the
chart speed is greater than or equal to 1600 mm/h and 101 mm/h on the pen model and dot
model, respectively.
7.7 Turning Printouts ON/OFF
To Next Page
