7-33
IM 04P01B01-01E
Setup Operations for Changing/Adding Functions (Basic Setting Mode)
7
7.21 Selecting to Show/Hide Setting Mode Menus
Select the menu for showing/hiding the Setting mode menus. This function is available
on version 1.31 or later.
Basic Setting mode cannot be entered when recording is in progress or when
computation is in progress on models with the computation function (/M1 option).
Procedure
Changing the Settings
1.
Hold down the
key for 3 seconds to enter Setting mode.
2.
Hold down the and keys simultaneously for 3 seconds to enter Basic
Setting mode.
3.
Press the key or SHIFT + key to select Select menu and then press the
key.
4.
Press the key with Set mode shown on the screen.
5.
Set each item and press the key.
Use the
key or SHIFT + key to select values.
For the procedure on how to enter values or characters, see section 4.2.
If you press the ESC key in the middle of the operation, the settings entered up to
then are cancelled, and the display returns to a higher level menu.
6.
When the Setting complete screen appears, do either of the following:
To correct the setting the
key.
If you are done, press the ESC key.
Range=On
Select whether to display Range in
Setting mode. Select On or Off.
Bias=On
Select whether to display Bias in
Setting mode. Select On or Off.
Menu=Set mode
Alarm=On
Select whether to display Alarm in
Setting mode. Select On or Off.
Unit=On
Select whether to display Unit in
Setting mode. Select On or Off.
Chart speed=On
Select whether to display Chart speed
in Setting mode. Select On or Off.
Aux=On
Select whether to display Aux in
Setting mode. Select On or Off.
To Next Page
