3.7 Printing Measured Values (Manual Printout)
Prints the measured values of all channels and the computed results when computation
mode is on.
Procedure
Starting the Manual Printout
1.
Press the
FUNC
key.
2.
Press the key to select Print out and then press the key.
Func=Print out
3.
Press the key with ManualStart shown on the screen.
Manual printout starts. The screen returns to the data display screen.
Print=ManualStart
For a printout example, see “Printout” on page 1-16.
Note
• When manual printout is executed, trend recording is suspended. However, the recorder
continues the measurement and alarm detection (in the background).
• When manual printout is complete, trend recording resumes.
• If an alarm occurs during the manual printout, the alarm is printed after the trend recording
resumes.
Aborting the Manual Printout
The following procedure is for aborting the manual printout that is in progress.
1.
Press the
FUNC
key.
2.
Press the key to select Print out and then press the key.
3.
Press the key with Manual Stop shown on the screen.
Manual printout stops. The screen returns to the data display screen.
Print=Manual Stop
* When the key or key is pressed while holding down the SHIFT key, the operation is reversed as
when the respective key is pressed by itself.
