IM 04P01B01-01E
1-34
1.10 Function Setup Guide
This section explains the settings necessary to use various functions of the recorder.
Read the section corresponding to the function you wish to use.
Note
This section contains all the settings related to each item. If the desired setting is the same as
the default value, you do not have to set it.
Item Description Reference
Section
Date/Time setting Use Clock in Setting mode. 5.5
DST Sets the date/time for switching between DST and standard time using Aux > DST in
Setting mode.
6.16
Setting initialization Use Initialize in Basic Setting mode to initialize the settings of Setting mode and Basic
Setting mode to their default values.
7.17
Measuring input functions
Item Description Reference
Section
Range and span of the TC, RTD, or DC voltage
Use Range in Setting mode. 5.1
1-5V • Range, span, and scale 5.1
Use Range in Setting mode.
• Unit 5.3
Use Unit in setting mode to set the unit after scaling.
• Low-cut 7.15
Use Personalize > Add function > 1-5V low-cut in Basic Setting mode and select
Use or Not.
5.1
If Use is selected, turn On/Off Low-cut using Range in Setting mode.
If Not is selected, the Low-cut item does not appear in the Range setting.
Scaling • Range, span, and scale 5.1
Use Range in Setting mode.
• Unit 5.3
Use Unit in setting mode to set the unit after scaling.
Square Root Computation • Range, span, and scale 5.1
Use Range in Setting mode.
• Unit 5.3
Use Unit in setting mode to set the unit after scaling.
• Low-cut 7.15
Use Personalize > Add function > SQRT low-cut in Basic Setting mode and select
Use or Not.
If Use is selected, set the Low-cut point using Range in Setting mode. 5.1
If Not is selected, the Low-cut item does not appear in the Range setting.
Unused channels Use Range > Skip in Setting mode to disable the trend recording (dot model) and
periodic printout of the target channel.
5.1
Bias Use Personalize > Add function > Bias in Basic Setting mode and select Use or Not. 7.15
If Use is selected, set the bias value that is added to the input using Bias in Setting
mode. If Not is selected, the Bias item does not appear.
6.12
Burnout detection function (TC input and 1-5V input) 7.3
Use Burnout in Basic Setting mode to set the burnout detection function for each
channel.
RJC of TC input Use RJC in Basic Setting mode to select whether to use the internal RJC function or an
external RJC function.
7.4
Filter (pen model) Use Filter in Basic Setting mode and select Use or Not. 7.12
If Use is selected, set the filter time constant using Aux > Filter in Setting mode. 6.2
If Not is selected, the Aux > Filter item does not appear.
