IM 04P01B01-01E
3-14
3.8 Printing the Recorder Settings
This section explains the procedure for printing the recorder settings. There are two sets
of settings that can be printed: List and Setup.
List: Prints the settings of Setting mode (input range for each channel, etc.)
Setup: Prints the settings of Basic Setting mode
Note
• The printout takes several minutes to tens of minutes to complete.
• When this printout is executed, trend recording is suspended. However, the recorder
continues the measurement and alarm detection (in the background).
• When the printout is complete, trend recording resumes.
• If an alarm occurs during the printout, the alarm is printed after the trend recording resumes.
Procedure
Starting the List Printout
1.
Press the
key.
2.
Press the key to select Print out and then press the key.
3.
Press the key to display List Start and then press the key.
The List printout starts. The screen returns to the data display screen.
Aborting the List Printout
1.
Press the
key.
2.
Press the key to select Print out and then press the key.
3.
Press the key to display List Stop and then press the key.
The List printout stops. The screen returns to the data display screen.
Starting the Setup Printout
1.
Press the
FUNC
key.
2.
Press the key to select Print out and then press the key.
3.
Press the key to display Setup Start and then press the key.
The Setup printout starts. The screen returns to the data display screen.
Aborting the Setup Printout
1.
Press the
FUNC
key.
2.
Press the key to select Print out and then press the key.
3.
Press the key to display Setup Stop and then press the key.
The Setup printout stops. The screen returns to the data display screen.
* When the key or key is pressed while holding down the SHIFT key, the operation is reversed as
when the respective key is pressed by itself.
To Next Page
