IM 04P01B01-01E
12-4
12.3 Recording Function Specifications
Trend Recording (Pen Model)
Item Specifications
Recording pen Disposable felt pen
Step response time Approx. 1 s (using the IEC61143 measurement method)
Number of pens Up to 4
Recording color Pen 1: Red, pen 2: Green, pen 3: Blue, pen 4: Violet
Trend recording Updates the data at the scan interval. Continuous recording.
Pen offset compensation Records by compensating for the offset of each pen along the time axis.
Chart speed 5 to 12000 mm/h (82 steps).
Zone recording Recording zone can be specified for each channel.
Recording width: 5 mm or more (1 mm steps)
Partial expanded recording Records by expanding the right or left side of the boundary position (the other section is reduced).
Boundary position: 1 to 99%
Boundary value: Within the recording span range
Trend Recording (Dot Model)
Item Specifications
Recording method Trend recording by a 6-color wire dot printer
Recording color Channel 1: Purple, channel 2: Red, channel 3: Green, channel 4: Blue, channel 5: Brown,
channel 6: Black
Trend recording interval Records at the following interval through a raster scan system.
Auto: Synchronizes to the chart speed and automatically sets to the interval so that the dots
do not overlap many times.
Fix: 10 s/6 channels (see section 12.5 for the recording interval on models with the
computation function (/M1 option)
Chart speed 1 to 1500 mm/h (1 mm steps)
Recording ON/OFF Recording can be turned ON/OFF for each channel.
Zone recording Same as the pen model.
Partial expanded recording Same as the pen model.
Chart Paper
Item Specifications
Printing width 100 mm
Type/Length Z-fold type. Approx. 16 m.
Chart paper feeding accuracy
Within ±0.1% After feeding 1000 mm and with respect to the print scale on the chart paper.
