Specifications
1
2
3
4
5
6
7
8
9
10
11
12
App
Index
Printouts (Pen Model)
Item Specifications
Recording pen (color) Plotter pen (purple)
Alarm printout Prints alarm occurrence/release.
Printout contents Occurrence (
)/release ( ) marks, channel number or tag, alarm type, alarm level, time, printout
buffer overflow mark.
Time printout format Selectable from hour:minute, hour:minute:second, month:day:hour:minute,
month:day:hour:minute:second, and year:month:day:hour:minute:second.
Alarm printout buffer Stores 8 occurrences of alarm information waiting to be printed.
Periodic printout Prints at specified time intervals from the reference time.
Interval Reference time: 00 hour 00 minute to 23 hour 00 minute (1 hour steps, minute fixed)
(see appendix 2) Auto: Automatically determined from the chart speed.
Manual: Select 10 min, 12 min, 15 min, 20 min, 30 min, 1 hour, 2 hours, 3 hours, 4 hours,
6 hours,8 hours, 12 hours, or 24 hours.
Mode Selectable from disable periodic printout, print instantaneous values, and print report data (report
mode).
Report data: Selectable from the average, minimum, maximum, minimum/maximum/average, sum
value, and instantaneous value.
Printout contents For instantaneous values: Date/Time, offset compensation ON/OFF, channel information
(measured value, alarm status, unit, delta computation ON/OFF, scale,
channel number or tag, recording color), chart speed (with time ticks)
For report data: Report start/end date/time, offset compensation ON/OFF, events, channel
information (value, unit, range change occurrence, scale, recording color), chart
speed (with time ticks)
Message printout Prints preset message strings.
Number of messages 5
Printout contents Time, message (up to 16 characters), printout buffer overflow mark.
Time printout format Selectable from hour:minute, hour:minute:second, month:day:hour:minute,
month:day:hour:minute:second, year:month:day:hour:minute:second, and not print.
Message printout buffer Stores 5 messages waiting to be printed.
Recording start printout Prints at the start of recording.
Printout contents Time and chart speed, printout buffer overflow mark.
Time printout format Selectable from hour:minute, hour:minute:second, month:day:hour:minute,
month:day:hour:minute:second, and year:month:day:hour:minute:second.
New chart speed printout Prints when the chart speed is changed.
Printout contents Chart speed and time, printout buffer overflow mark.
Time printout format Selectable from hour:minute, hour:minute:second, month:day:hour:minute,
month:day:hour:minute:second, and year:month:day:hour:minute:second.
Manual printout Prints the measured values of all channels and the computed results when computation mode is
on.
Printout contents Measured values of all channels at that point.
Trend recording is temporarily suspended.
Setting printout (List) Prints the settings of items in Setting mode.
Printout contents Range setting, alarm setting, etc.
Trend recording is temporarily suspended.
Setting printout (Setup) Prints the settings of items in Basic Setting mode.
Printout contents Basic alarm specifications, basic recording specifications, etc.
Trend recording is temporarily suspended.
Items dependent on the chart speed
Chart speed Periodic printout
Alarm printout
Message printout
Record start printout
New chart speed printout
5 to 9 mm/h Not printed Printed
10 to 1500 mm/h Printed Printed
1600 mm/h or higher Not printed Not printed
Chart speed Periodic printout interval
10 to 18 mm/h 8 hours
20 to 36 mm/h 4 hours
40 to 72 mm/h 2 hours
75 to 135 mm/h 1 hour
150 to 180 mm/h 30 minutes
200 to 320 mm/h 20 minutes
350 to 1500 mm/h 10 minutes
Date printout format Select the printout format of the date from Y/M/D, M/D/Y, D/M/Y, D.M.Y, and M.D.Y. The format
applies to the date printout of all printout items (version 1.11 and later).
12.3 Recording Function Specifications
