IM 04P01B01-01E
12-6
Printout (Dot Model)
Item Specifications
Recording Dot printing.
Channel printout Prints the channel number or tag beside the trend recording every approx. 25 mm of chart paper.
Channel printout ON/OFF selectable.
Alarm printout Prints alarm occurrence/release.
Printout contents Occurrence (
, red)/release ( , blue) marks, channel number or tag, alarm type, alarm level,
time, printout buffer overflow mark.
Time printout format Selectable from hour:minute, hour:minute:second, month day hour:minute,
month day hour:minute:second, and month day year hour:minute:second.
Alarm printout buffer Stores 12 occurrences of alarm information waiting to be printed.
Periodic printout Prints at specified time intervals from the reference time.
Interval (see appendix 2) Same as the pen model.
Measured value Same as the pen model.
Printout contents For instantaneous values: Same as the pen model except offset compensation ON/OFF and
recording color are not printed.
For report data: Same as the pen model except offset compensation ON/OFF and
recording color are not printed.
Message printout Same as the pen model.
Recording start printout Same as the pen model. With time ticks.
New chart speed printout Same as the pen model. With time ticks.
Manual printout Same as the pen model.
Setting printout (List) Same as the pen model.
Setting printout (Setup) Same as the pen model.
Items dependent on the chart speed
Chart speed Channel printout Periodic printout
Alarm printout
Message printout
Record start printout
New chart speed printout
1 to 9 mm/h Printed Not printed Printed
10 to 100 mm/h Printed Printed Printed
101 to 1500 mm/h Not printed Not printed Not printed
Chart speed Periodic printout interval
10 to 19 mm/h 8 hours
20 to 39 mm/h 4 hours
40 to 79 mm/h 2 hours
80 to 100 mm/h 1 hour
Date printout format Same as the pen model.
Values for Special Measured Values
Same as “Special values” for the digital display on page 12-8.
12.3 Recording Function Specifications
