12-1
IM 04P01B01-01E
Specifications
12
12.1 Input Specifications
Number of Inputs and Scan Interval on the Pen Model
Item Specifications
Number of inputs 1, 2, 3, or 4
Scan interval 125 ms
Number of Inputs and Scan Interval on the Dot Model
Item Specifications
Number of inputs 6
Scan interval 1 s (when the integration time of the A/D converter is 20 ms or 16.7 ms)
2.5 s (when the integration time of the A/D converter is 100 ms)
Input Type
Item Specifications
Input type DC voltage, 1-5V, TC, RTD, DI (ON/OFF input), DC current (by adding an external shunt resistor)
Input Type and Measurable Range
Input Range Type Measurable Range
Volt 20 mV –20.00 to 20.00 mV
60 mV –60.00 to 60.00 mV
200 mV –200.0 to 200.0 mV
2 V –2.000 to 2.000 V
6 V –6.000 to 6.000 V
20 V –20.00 to 20.00 V
50 V –50.00 to 50.00 V
1-5V (0.800 to 1.200 V range) to (4.800 to 5.200 V range)
TC R
1
0.0 to 1760.0°C 32 to 3200°F
S
1
0.0 to 1760.0°C 32 to 3200°F
B
1
0.0 to 1820.0°C 32 to 3308°F
K
1
–200.0 to 1370.0°C –328 to 2498°F
E
1
–200.0 to 800.0°C –328.0 to 1472.0°F
J
1
–200.0 to 1100.0°C –328.0 to 2012.0°F
T
1
–200.0 to 400.0°C –328.0 to 752.0°F
N
1
0.0 to 1300.0°C 32 to 2372°F
W
2
0.0 to 2315.0°C 32 to 4199°F
L
3
–200.0 to 900.0°C –328.0 to 1652.0°F
U
3
–200.0 to 400.0°C –328.0 to 752.0°F
WRe
4
0.0 to 2400.0°C 32 to 4352°F
RTD PT (Pt100)
5
–200.0 to 600.0°C –328.0 to 1112.0°F
JPT (JPt100)
5
–200.0 to 550.0°C –328.0 to 1022.0°F
DI Level 0: Less than 2.4 V, 1: Greater than or equal to 2.4 V
Within ±6 V
Contact
6
0: Open, 1: Closed
1 R, S, B, K, E, J, T, N: IEC 584-1 (1995), DIN IEC 584, JIS C1602-1995
2 W: W-5% Re/W-26% Re (Hoskins Mfg. Co.), ASTM E988
3 L: Fe-CuNi, DIN 43710, U: Cu-CuNi, DIN 43710
4 WRe: W-3%Re/W-25%Re (Hoskins Mfg. Co.)
5 Pt100: JIS C 1604:2013, IEC 60751:2008, DIN EN 60751:2009
JPt100: JIS C1604-1989, JIS C1606-1989
Measurement current: i = 1 mA (Pt100, JPt100)
6 Detectedcurrentvalue:approx.10μA
Chapter 12 Specifications
