11.7 Recommended Replacement Periods for Worn
Parts
To preserve the reliability of the recorder and to use the recorder in good condition for
an extended time, it is recommended that periodic replacements be made on parts. The
replacement parts may change to accommodate preventive maintenance over extended
time. Be sure to check with your nearest YOKOGAWA dealer.
The table below shows the recommended replacement period for expendable parts.
The replacement period shown here applies when the recorder is used under standard
operating conditions. For the actual replacement period, consider the actual conditions of
use.
Replacement of parts other than the chart paper, pen, ribbon cassette, and internal light
LED will be carried out by a YOKOGAWA engineer or an engineer certified by YOKOGAWA.
Contact your nearest YOKOGAWA dealer when such replacement is necessary.
Note
The replacement period of the display and the internal light LED is the half life of the brightness.
The deterioration of brightness varies depending on the condition of use, and its determination
is subjective. Consider these facts for determining the actual replacement period.
Pen Model
Item
Replacement
Period
Part Name Part No. Note
Quantity
Used
Z-fold chart paper 33 days CHART B9565AW When used at 20 mm/h 1
Felt pen 2 km PEN ASSY
B9902AM
B9902AN
B9902AP
B9902AQ
Red
Green
Blue
Violet
At a pen speed
of 10 cm/s
1 each
Plotter pen
60,000
characters**
PEN ASSY B9902AR When printing continuously 1
Display 5 years* DISPLAY ASSY B8800CA 1
Chart paper feed
motor
5 years MOTOR ASSY B9962EJ 1
Plotter carriage 5 years CARRIAGE ASSY B8800DJ 1
Plotter motor 5 years MOTOR ASSY B8800DT For the X-axis 1
Lever bearing 5 years BEARING B9900RP For the plotter 1
Pen servo 5 years SERVO ASSY B8800GG
Shared by all pens (excludes
the pen arm ASSY)
1 to 4
Internal light LED 2 years* LED ASSY B8800CR 1
* The half life of the brightness at the factory default brightness setting.
** Smearing may occur around the ridge-folding part of the chart paper.
Dot Model
Item
Replacement
Period
Part Name Part No. Note
Quantity
Used
Z-fold chart paper 33 days CHART B9565AW When used at 20 mm/h 1
Ribbon cassette 3 months RIBBON CASSETTE B9901AX 1
Display 5 years* DISPLAY ASSY B8800CA 1
Chart paper feed
motor
5 years MOTOR ASSY B9962EJ 1
Lever 3 years LEVER ASSY B9901EK For the carriage 1
Pulley 3 years PULLY B9963CJ For the carriage 2
Carriage motor 5 years MOTOR ASSY B9963CF 1
Carriage 5 years CARRIAGE ASSY B9963CL 1
Ribbon shift motor 5 years MOTOR ASSY B9962EJ 1
Ribbon shift gear 5 years GEAR
B8801BX
B8801BW
1 each
Ribbon feed motor 5 years MOTOR ASSY B9962EJ 1
Ribbon feed gear 5 years GEAR
B9901HL
B9901HM
B9901HN
1 each
Internal light LED 2 years* LED ASSY B8800CR 1
* The half life of the brightness at the factory default brightness setting.
