7-41
IM 04P01B01-01E
Setup Operations for Changing/Adding Functions (Basic Setting Mode)
7
Explanation
Batch
Use: When starting/stopping recording, performs Start printout and End printout. You
can now set up “Lot No.,” “Dual comment,” and, in Setting mode, “Batch.”
Not: Do not perform Start printout/End printout.
Lot No.
Batch name = Batch No. (character string) and Lot No. (number)
4: Prints out a 4-digit lot number. You can now set this under “Lot No.” in Setting
mode.
6: Prints out a 6-digit lot number. You can now set this under “Lot No.” in Setting
mode.
Not: Does not perform printout of the lot number.
Dual comment
Use: You can now select Start printout 2 and End printout 2 in Setting mode’s Mode.
Not: There are no Start printout 2 and End printout 2 choices in Setting mode’s Mode.
MSG Format
Use: You can now set the MSG format in Setting mode.
Not: The MSG format item is not displayed in Setting mode.
<Related Topics> Setting the start printout and end printout: Section 6.14
Setting the batch comment switch: Section 7.18
Setting t
he message format: section 6.15
Note
Enabling the header printout (/BT1 option) function performs the following operation.
• When the power supply stops and then resumes, recording remains stopped.
7.24 Enabling Start Printout, End printout, and Message Format (/BT1 Option)
To Next Page
