YOKOGAWA MuR10000 User Manual

9-3
IM 04P01B01-01E
Operations Related to the Computation Function (/M1 Option)
9.2 Setting the Computing Equation
1
2
3
4
5
6
7
8
9
10
11
12
App
Index
Each time you press the CHARACTER key the display changes as shown below.
Pressing the
key or SHIFT + key switches the character within the selected
character type and displays the character at the cursor position.
Display (
CHARACTER
key)
Description Character (
key)
01... Measurement channel
numnber
Pen model: 01 to 04
Dot model: 01 to 06
0A... Computation channel
number
Pen model: 0A, 0B, 0C, 0D, 0E, 0F, 0G, 0J
Dot model: 0A, 0B, 0C, 0D, 0E, 0F, 0G, 0J,
0K, 0M, 0N, 0P
+, –, *, /... Symbol and space +, –, *, /, (, ), space
Function Function SQR(, ABS(, LOG(, EXP(, .EQ., .NE., .GT.,
.LT., .GE., .LE., AND, NOT, XOR, OR,
TLOG.AVE(, TLOG.MAX(, TLOG.MIN(,
TLOG.SUM(, TLOG.P-P(, space
K01-K30 Constant K01 to K30
D01-D05 Status of the remote D01 to D05
control terminals
C01-C12 Communication input data Pen model: C01 to C08
Dot model: C01 to C12
Ins DISP Insert a character
Del DISP Delete a character
Clear DISP Delete the entire string
Copy DISP Store the entire string in
the memory
Past DISP Paste the string in the
memory
Inserting a Character
Press the key or SHIFT + key to move the cursor to the position where the
character is to be inserted.
Press the CHARACTER key or SHIFT + CHARACTER key to show Ins DISP and then
press the
key. A space for one character is inserted. Enter the character.
Deleting a Character
Use the key or SHIFT + key to move the cursor to the character to be deleted.
Press the CHARACTER key or SHIFT + CHARACTER key to show Del DISP and then
press the
key. The character is deleted.
Deleting an Entire Character String
Press the CHARACTER key or SHIFT + CHARACTER key to show Clear DISP and
then press the
key. The entire character string is deleted.
Copying & Pasting a Character String
Show the copy source character string.
Press the CHARACTER key or SHIFT + CHARACTER key to show Copy DISP and
then press the
key. The character string is saved to the memory.
Show the copy destination.
Press the CHARACTER key or SHIFT + CHARACTER key to show Paste DISP and
then press the
key. The character string is pasted.
