IM 04P01B01-01E
9.5 Setting the Alarm
9-12
Explanation
Alarm Type
Symbol Name
H High limit alarm
L Low limit alarm
T Delay high limit alarm*
t Delay low limit alarm*
* Selectable only when the alarm delay function is enabled. See section 7.15.
If delay high limit alarm or delay low limit alarm is specified, set the alarm delay time.
<Related Topics>
Setting the delay time of the delay high limit alarm or delay low limit alarm: Section 9.11
Enabling the alarm delay function: Section 7.15
Setting the alarm hysteresis: Section 7.1
Alarm Value
Can be set to a value in the range of –9999999 to 99999999 excluding the decimal
(–9999999 to 99999999 is the displayable range).
Relay No.
The selectable relay numbers are listed below.
I01 and I02 on the /A1 option
I01, I02, I03, and I04 on the /A2 option
I01, I02, I03, I04, I05, and I06 on the /A3 option
To Next Page
