IM 04P01B01-01E
12-14
FAIL/Chart End Detection and Output (/F1)
Item Specifications
FAIL output Relay output on CPU error
Relay operation Energized during normal operation and de-energized on CPU error. Non-hold operation.
Chart end detection output Stops recording and outputs a relay signal when the remaining amount of chart paper is approx.
2 cm. Also, turns ON the words CHART END on the display.
Relay operation The relay is energized when the above conditions are met. Non-hold operation.
Contact rating 250 VAC (50/60 Hz)/3 A, 250 VDC/0.1 A (for resistor load)
Clamped Input Terminal (/H2)
Item Specifications
Measuring input terminal Uses clamped input terminals.
Non-Glare Door Glass (/H3)
Item Specifications
Door glass Uses a door glass with minimal reflection.
Computation Function (/M1)
Item Specifications
Number of computation channels
Pen model: 8 channels, dot model: 12 channels
Operation General arithmetic operations: Four arithmetic operations, square root, absolute, common
logarithm,exponential,power,relationaloperations(<,≤,>,≥,=,≠),
logical operations (AND, OR, NOT, XOR)
Statistical operations (TLOG): Average, max., min., sum, and max. – min. for each interval
Constants Up to 30 constants can be defined
Range: –9.9999E+29 to –1.0000E–30, 0, 1.0000E–30 to 9.9999E+29
Symbol: K01 to K30
Communication input data Digital data via communication can be used in computations other than statistical computation
(TLOG)
Number of communication input data points: 8 (pen model), 12 (dot model)
Range: –9.9999E+29 to –1.0000E–30, 0, 1.0000E–30 to 9.9999E+29
Symbol: C01 to C12
Remote input Use remote input status (0/1) in equations
Number of inputs: 5
Symbol: D01 to D05
Computation accuracy 32-bit floating-point computation (excluding TLOG computation)
Computation range Computed values throughout the computation remains within approx. ±3.4×10
38.
Equation Defined using up to 120 characters.
Execution interval Scan interval
TLOG timer Performs statistical calculation for each interval specified by the timer.
Number of timers 3 (periodic printout timer, timer 1, and timer 2).
Timer 1 and 2 modes Absolute or relative
Reset TLOG data can be reset at each interval.
Printout Printout at each interval is possible.
Trend recording
Recording span –9999999 to 99999999, decimal place arbitrary.
Unit Up to 6 characters
Recording methods Zone recording and partial expanded recording available.
Pen Measurement channels and computation channels can be assigned arbitrarily to pens.
Dot printing Trend recording of measurement and computation channels. The fastest dot printing interval is as
follows:
Number of channels being trend recorded Fastest dot printing interval
6 or less 10 s
7 to 12 15 s
13 to 18 20 s
12.5 Specifications of Optional Functions
