YOKOGAWA MuR10000 User Manual

IM 04P01B01-01E
12-16
Item Specifications
Measurement and recording accuracy: See “Standard Performance” on page 12-20.
Input Type Measurement Accuracy Recording Accuracy
Thermocouple
(excludes RJC
accuracy)
PR40-20
0 to 450°C
450 to 750°C
750 to 1100°C
1100 to 1900°C
Not warranted
±(0.9% of rdg + 3.2°C)
±(0.9% of rdg + 1.3°C)
±(0.9% of rdg + 0.4°C)
Measurement accuracy
±(0.3% of recording span)
PLATINEL ±(0.25% of rdg + 2.3°C)
NiNiMo ±(0.25% of rdg + 0.7°C)
W/WRe26
0 to 400°C
400 to 2400°C
±15.0°C or less
±(0.2% of rdg + 2.0°C)
Type N (AWG14) ±(0.2% of rdg + 1.3°C)
Kp vs Au7Fe
0 to 20 K
20 to 300 K
±4.5 K
±2.5 K
RTD
Pt25 ±(0.15% of rdg + 0.6°C)
Pt50 ±(0.3% of rdg + 0.6°C)
Ni100 (SAMA)
±(0.15% of rdg + 0.4°C)Ni100 (DIN)
Ni120
J263*B
0 to 40 K
40 to 300 K
±3.0 K
±1.0 K
Cu53 ±(0.15% of rdg + 0.8°C)
Cu100 ±(0.2% of rdg + 1.0°C)
Reference junction
compensation accuracy
When input terminal temperature balanced (60 minutes after power on)
PLATINEL, NiNiMo, W/WRe26, or Type N (AWG14): ±1.0°C
No RJC for PR40-20 and Kp vs Au7Fe (fixed to 0°C)
Remote Control 5 Points (/R1)
Item Specifications
Number of input terminals 5
Input type Isolated from the main circuitry through a photocoupler, built-in isolated power supply for the input
terminals, and shared common
Input type and signal level
Voltage-free contact Contactclosedat200Ωorlessandcontactopenat100kΩorgreater
Open collector ON voltage: 0.5 V or less (sink current 30 mA or more), leakage current when OFF: 0.25 mA or less
Allowable input voltage 5 VDC
Signal type Edge, level, or trigger (250 ms or more)
Operation
Perform the following control operations by applying a given signal to the remote signal input terminal.
• Start/stop recording (edge)
• Alarm ACK (trigger)
• Set the clock (adjust the clock to the nearest hour with the contact input, trigger)
Time When Signal Is Input Procedure
00 min 00 s to 01 min 59 s Truncatestheminutesandseconds.Example:10:00:50→10:00:00
58 min 00 s to 59 min 59 s Roundsuptheminutesandseconds.Example:10:59:50→11:00:00
02 min 00 s to 57 min to 59 s No operation
• Manual printout (trigger)
• Message 1 to 5 printout (trigger)
• Switch the chart speed (level)
• Start/stop computation (/M1 option) (edge)
• Reset computation (/M1 option) (trigger)
• Priority to remote recording (/BT1 option) (edge)
• Batch comment switching (/BT1 option) (level)
• Start/stop data saving (/EM1 option) (edge)
Portable Type (/H5x)
Item Specifications
Installation Desktop type (with a carrying handle)
External dimensions 144 (W) × 187 (H) × 285 (D) mm (including the handle and feet)
Weight
Add 1.0 kg to the weight given in General Specifications (see section 12.6, excluding the power cord)
Standard accessories* With a power cord
* Panel mounting brackets are not included.
12.5 Specifications of Optional Functions
