IM 04P01B01-01E
12-24
12.7 Dimensional Drawings
Portable Type (/H5x Option)
138.5 (5.45)
144 (5.67)
141.5 (5.57)
12.4
(0.49)
144 (5.67)
187 (7.36)
27.5
(1.08)
285 (11.2)
176 (6.93)
81.5 (3.21)
100-240V~
50/60Hz
40VA MAX
Unit: mm (approx. inch)
Unless otherwise specified, tolerance is ±3%
(however, tolerance is ±0.3 mm when below 10 mm).
