Appendix 1 Periodic Printout and Printout Using the TLOG Timer (/M1 Option)
App-4
Printout Using the TLOG Timer (/M1 Option)
Prints the computed values of computation channels for each interval determined by the
TLOG timer.
Pen Model
Offset compensation mark/event
Alarm
Unit
Channel number
or tag
Measured
value
Date
Time
Channel data
Scale
Recording color
Timer
Mar.31.2004
15:50*TPR
TAG-00A 1UNIT0A
B 1.0
C L 1.00
G -1.0
J -1.00UNIT0J
-100 100
TAG-00A UNIT0A
RED
TLOG1
• Date/Time
The date/time when the printout using the TLOG timer was executed.
• Offset compensation mark, scale, and recording color
These are the same as with the periodic printout of the pen model.
• Event
This is the same as with the report mode of the periodic printout of the pen model.
• Channel data
Prints the computation channel numbers (A to J) or tags, computed values, and unit.
• Alarm
This is the same as with the instantaneous mode of the periodic printout of the pen
model.
• Timer
Prints the timer number being used.
Dot Model
Event
Unit
Channel number
or tag
Measured value
Date
Time
Channel data
Scale
Timer
Alarm
Mar.31.2004
15:50*TPR
TAG-00A 1UNIT0A
C L 1.00
D 100.00UNIT0D
E 1.0000%
G -1.0
J -1.00UNIT0J
-100 100
TAG-00A UNIT0A
TLOG2
• Date/Time
The date/time when the printout using the TLOG timer was executed.
• Event
This is the same as with the report mode of the periodic printout of the pen model.
• Channel data
Prints the computation channel numbers (A to P) or tags, computed values, and unit.
• Alarm
This is the same as with the instantaneous mode of the periodic printout of the pen
model.
• Scale
These are the same as with the periodic printout of the pen model.
• Timer
Prints the timer number being used.
