YOKOGAWA UM33A User Manual

17-7
IM 05P03D21-01EN
Parameters
17
17.1ListofParameters
PV-relatedSettingMenu(Menu:PVS)
Parameter
symbol
Name
Display
level
Settingrange Initial value
BS PV input bias EASY
-100.0 to 100.0% of PV input range
span (EUS)
0.0 % of PV
input range
span
FL PVinputlter EASY OFF, 1 to 120 s OFF
PEAK PV peak value EASY
Read only
-5.0 to 105.0% of PV input range
(EU)
-
BOTM PV bottom value EASY -
10-segmentLinearizerSettingMenu(Menu:PYS1andPYS2)
Parameter
symbol
Name
Display
level
Settingrange Initial value
A1 to A11
10-segment
linearizer input 1 to
11
PRO
-66.7 to 105.0% of input range (EU)
Output linearizer: -5.0 to 105.0%
0.0%
B1 to B11
10-segment
linearizer output 1
to 11
PRO
10-segment linearizer bias: -66.7
to 105.0% of input range span
(EUS)
10-segment linearizer
approximation: -66.7 to 105.0%
of input range (EU)
Output linearizer: -5.0 to 105.0%
0.0%
PMD
10-segment
linearizer mode
PRO
0: 10-segment linearizer bias
1: 10-segment linearizer
approximation
0
10-segment linearizer parameters are four groups, the group number (1 or 2) is displayed on Group
display.
