YOKOGAWA UM33A User Manual

17-12
IM 05P03D21-01EN
DisplayFunctionSettingMenu(Menu:DISP)
Parameter
symbol
Name
Display
level
Settingrange Initial value
PCMD
Active color PV
display switch
EASY
0: Fixed in white
1: Fixed in red
2: Link to alarm 1 (Alarm OFF:
white, Alarm ON: red)
3: Link to alarm 1 (Alarm OFF: red,
Alarm ON: white)
4: Link to alarm 1 or 2 (Alarm OFF:
white, Alarm ON: red)
5: Link to alarm 1 or 2 (Alarm OFF:
red, Alarm ON: white)
6: PV limit (Within range: white,
Out of range: red)
7: PV limit (Within range: red, Out
of range: white)
10: Link to DI (ON: red, OFF:
white)
0
PCH
PV color change
high limit
EASY
Set a display value when in PV
limit.
-19999 to 30000 (Set a value
within the input range.)
Decimal point position depends on
the input type.
0
PCL
PV color change
low limit
EASY 0
EV1 to EV8
EV1 to EV8
display condition
registration
PRO
Setting range: 4001 to 5344
OFF: Disable
4321: Link to alarm 1 (Lit when the alarm
occurs)
4322: Link to alarm 2 (Lit when the alarm
occurs)
4323: Link to alarm 3 (Lit when the alarm
occurs)
4325: Link to alarm 4 (Lit when the alarm
occurs)
4326: Link to alarm 5 (Lit when the alarm
occurs)
4327: Link to alarm 6 (Lit when the alarm
occurs)
4329: Link to alarm 7 (Lit when the alarm
occurs)
4330: Link to alarm 8 (Lit when the alarm
occurs)
5025 to 5026: Link to DI1-DI2 (Lit when the
contact is closed)
5153 to 5155: Link to AL1-AL3 (Lit when the
contact is closed)
5156: Link to AL4 (Lit when the contact is
closed)
5169 to 5173: Link to DO11-DO15 (E1-
terminal area) (Lit when the contact is
closed)
For other functions, see the UTAdvanced
Series Communication Interface User’s
Manual.
EV1: 4321
EV2: 4322
EV3: 4323
EV4: 4325
PV.D
PV display area
ON/OFF
PRO
OFF: Nondisplay, ON: Display
ON
SP.D
Setpoint display
area ON/OFF
PRO ON
STS.D
Status display area
ON/OFF
PRO ON
17.2ListofParameters
