17-13
IM 05P03D21-01EN
Parameters
17
DisplayFunctionSettingMenu(Menu:DISP)(Continuedfrompreviouspage)
Parameter
symbol
Name
Display
level
Settingrange Initial value
SPD Scroll speed PRO (Slow) 1 to 8 (Quick) 4
GUID
Guide display ON/
OFF
STD
OFF: Nondisplay
ON: Display
ON
HOME
Home Operation
Display setting
PRO
PV: Valve Position Display
CS1 to CS5: SELECT Display 1 to 5
PV
ECO Economy mode STD
OFF: Disable
1: Economy mode ON (All
indications except PV display
OFF)
2: Economy mode ON (All
indications OFF)
3: Brightness 10 % (All indications)
OFF
BRI Brightness EASY (Dark) 1 to 5 (Bright) 3
B.PVW
White brightness
adjustmentofPV
display
PRO
AdjuststhewhitebrightnessofPV
display.
(Dark) -4 to 4 (Bright)
0
B.PVR
Red brightness
adjustmentofPV
display
PRO
AdjuststheredbrightnessofPV
display.
(Dark) -4 to 4 (Bright)
0
B.SP
Brightness
adjustmentofSP
display
PRO
AdjuststhebrightnessofSP
display.
(Dark) -4 to 4 (Bright)
0
B.STS
Brightness
adjustmentof
Status indicator
PRO
AdjuststhebrightnessofStatus
indicator.
(Dark) -4 to 4 (Bright)
0
D.CYC
Display update
cycle
PRO
1: 100 ms
2: 200 ms
3: 500 ms
4: 1 s
5: 2 s
2
OP.JP
Autoreturn to
operation display
PRO
Automatically returned to the
Operation Display when there has
been no keystroke operation for 5
minutes.
OFF, ON
ON
MLSD
Leastsignicant
digital mask of PV
display
STD
OFF:Withleastsignicantdigit
ON:Withoutleastsignicantdigit
OFF
MKTP
Method for least
signicantdigital
mask of PV display
STD
0: Rounding
1: Rounding-off
0
SELECTDisplaySettingMenu(Menu:CSEL)
Parameter
symbol
Name
Display
level
Settingrange Initial value
CS1toCS5
SELECT Display-1
to -5registration
STD OFF, 2301 to 5000 OFF
KeyLockSettingMenu(Menu:KLOC)
Parameter
symbol
Name
Display
level
Settingrange Initial value
U.PV
PV Analog Input
Display lock
PRO
OFF: Display
ON: Nondisplay
OFF
COM.W
Communication
write enable/disable
STD
OFF: Enable
ON: Disable
OFF
DATA
Front panel
parameter data key
lock
STD
OFF: Unlock
ON: Lock
(when Operation Display
only)
OFF
17.2ListofParameters
