YOKOGAWA UM33A User Manual

17-14
IM 05P03D21-01EN
MenuLockSettingMenu(Menu:MLOC)
Parameter
symbol
Name
Display
level
Settingrange Initial value
CTL [CTL] menu lock PRO
OFF: Display
ON: Nondisplay
OFF
PV [PV] menu lock PRO
MPV [MPV] menu lock PRO
OUT [OUT] menu lock PRO
R485 [R485] menu lock PRO
CC-L [CC-L] menu lock PRO
KEY [KEY] menu lock PRO
DISP [DISP] menu lock PRO
CSEL [CSEL] menu lock PRO
KLOC [KLOC] menu lock PRO
DI.SL [DI.SL] menu lock PRO
DI.D [DI.D] menu lock PRO
ALM [ALM] menu lock PRO
DO [DO] menu lock PRO
I/O [I/O] menu lock PRO
SYS [SYS] menu lock PRO
INIT [INIT] menu lock PRO
VER [VER] menu lock PRO
LVL [LVL] menu lock PRO
AL [AL] menu lock PRO
OFF: Display
ON: Nondisplay
OFF
ALRM [ALRM] menu lock PRO
PVS [PVS] menu lock PRO
PYS1 [PYS1] menu lock PRO
PYS2 [PYS2] menu lock PRO
DIFunctionRegistrationMenu(Menu:DI.SL)
Parameter
symbol
Name
Display
level
Settingrange Initial value
RST
PV peak and
bottom values reset
STD
Set an I relay number of contact
input.
Set “OFF” to disable the function.
Standard terminals
DI1: 5025, DI2: 5026
5025
LAT Latch release STD 5026
LCD
LCD backlight ON/
OFF switch
STD OFF
PVRW PV red/white switch STD OFF
MG1
Message display
interruption 1
PRO OFF
MG2
Message display
interruption 2
PRO OFF
MG3
Message display
interruption 3
PRO OFF
MG4
Message display
interruption 4
PRO OFF
17.2ListofParameters
