YOKOGAWA UM33A User Manual

17-15
IM 05P03D21-01EN
Parameters
17
DI1-DI2ContactTypeSettingMenu(Menu:DI.D)
Parameter
symbol
Name
Display
level
Settingrange Initial value
DI1.D DI1 contact type PRO
0: The assigned function is
enabled when the contact input
is closed.
1: The assigned function is
enabled when the contact input
is opened.
0
DI2.D DI2 contact type PRO 0
AL1-AL4FunctionRegistrationMenu(Menu:ALM)
Parameter
symbol
Name
Display
level
Settingrange Initial value
AL1.S
AL1 function
selection
STD
Set an I relay number.
Setting range: 4001 to 6000
No function: OFF
Alarm 1: 4353
Alarm 2: 4354
Alarm 3: 4355
Alarm 4: 4357
Alarm 5: 4358
Alarm 6: 4359
Alarm 7: 4361
Alarm 8: 4362
FAIL (Normally ON) output: 4256
4353
AL2.S
AL2 function
selection
STD 4354
AL3.S
AL3 function
selection
STD 4355
AL4.S
AL4 function
selection
STD 4357
AL1.D AL1 contact type PRO
0: When the event of assigned
function occurs, the contact
output is closed.
1: When the event of assigned
function occurs, the contact
output is opened.
0
AL2.D AL2 contact type PRO 0
AL3.D AL3 contact type PRO 0
AL4.D AL4 contact type PRO 0
DOSettingMenu(Menu:DO)(E1andE4terminalarea)
Parameter
symbol
Name
Display
level
Settingrange Initial value
DO1.S
DO11 function
selection
STD
Same as AL1.S.
Set “OFF” to disable the function.
4358
DO2.S
DO12 function
selection
STD 4359
DO3.S
DO13 function
selection
STD 4361
DO4.S
DO14 function
selection
STD 4362
DO5.S
DO15 function
selection
STD 4256
DO1.D DO11 contact type PRO
0: When the event of assigned
function occurs, the contact
output is closed.
1: When the event of assigned
function occurs, the contact
output is opened.
0
DO2.D DO12 contact type PRO 0
DO3.D DO13 contact type PRO 0
DO4.D DO14 contact type PRO 0
DO5.D DO15 contact type PRO 0
I/ODisplayMenu(Menu:I/O)
Parameter
symbol
Name
Display
level
Readonly
KEY Key status PRO
See Chapter 12.
X000 DI1-DI2 status (equipped as standard) PRO
Y000 AL1-AL4 status (equipped as standard) PRO
Y100 DO11-DO15 status (E1-terminal area) PRO
17.2ListofParameters
