Light-loader Communication

Use the LL50A to set parameters. Attach the adapter to the front of the indicator to

communicate.

► Light-loaderfunction:LL50AParameterSettingSoftwareUser’sManual

Dedicated cable

LL50A

Parameter Setting Software

To USB terminal

Light-loader

adapter

MaintenancePortCommunication(Powersupplyisnotrequiredforthe

UM33A)

Maintenance port is used to connect with the dedicated cable when using LL50A

Parameter Setting Software (sold separately). The parameters can be set without

supplying power to the UM33A.

Dedicated cable

LL50A Parameter Setting Software

To USB terminal

CAUTION

When using the maintenance port, do not supply power to the indicator. Otherwise, the

indicator does not work normally.

If power is supplied to the indicator while the cable is connected, or the cable is

connected to the indicator already turned on, unplug the cable and turn on the indicator

again. The indicator returns to the normal condition.
