YOKOGAWA UM33A User Manual

7-9
IM 05P03D21-01EN
Input (PV) Functions
7
SettingDetails
Parameter
symbol
Name Displaylevel Settingrange Menusymbol
A1 to A11
10-segment
linearizer
input
PRO
-66.7 to 105.0% of input range
(EU)
PYS1
B1 to B11
10-segment
linearizer
output
PRO
10-segment linearizer bias: -66.7
to 105.0% of input range span
(EUS)
10-segment linearizer
approximation: -66.7 to 105.0%
of input range (EU)
PMD
10-segment
linearizer
mode
PRO
0: 10-segment linearizer bias
1: 10-segment linearizer
approximation
Note1: When each parameter is displayed, the group number (1 to 4) is displayed on Group display.
Parameters are set in the following order.
(1) The PV input is set by the parameter in PYS1 menu.
► Where the 10-segment linearizer function is used; Function block diagrams in 8.1 Function block
diagram
(2) PMD: Specifies whether to use it as a 10-segment linearizer bias or a 10-segment
linearizer approximation.
(3) A1 to A11, B1 to B11: Sets the 10-segment linearizer input and 10-segment linearizer
output.
PV input: PV input range or PV input range span
Note
• Set the 10-segment linearizer so that it increases monotonically.
7.1SettingFunctionsofPVInput
