Data Capture 4 - 13
Figure 4-21 Bluetooth Pairing Utility
4. Using the DS3678, scan the bar code on the screen.
The DS3678 emits a high/low/high/low beeps. The Scan LED flashes green indicating that the DS3678 is
attempting to establish connection with the TC51. When connection is established, the Scan LED turns off and
the DS3678 emits one string of low/high beeps.
5. On the TC51 touch .
Pairing Using Bluetooth Human Interface Device
To pair the DS3678 with the TC51 using HID:
1. Remove the battery from the DS3678 scanner.
2. Replace the battery.
3. After the DS3678 reboots, scan the bar code below to place the DS3678 in HID mode.
Figure 4-22 HID Bluetooth Classic Bar Code
4. On the TC51, swipe down with two fingers from the status bar to open the quick access panel and then touch
.
