Zebra TC51 User Manual

Accessories 6 - 5
1-Slot USB Charge Cradle
The 1-Slot USB Charge Cradle:
• Provides 5 VDC power for operating the device.
• Charges the device’s battery.
• Provides USB communication with host computer.
Figure 6-1 1–Slot USB Charge Cradle
Charging the Device
To charge a device:
1. Insert the device into the slot to begin charging.
CAUTION Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page
7-2.
Power LED
Cup Insert
NOTE If the device has a Rugged Boot, remove the cup insert before inserting the device. See TC51 Touch
Computer Integrator Guide for Android Version 6.0.1 for details.
By default, the device includes an interface connector. If the interface connector is removed for USB Type
C cable connectivity, then it must be replaced before charging or receiving an Ethernet IP address if
placed in a cradle.

Zebra TC51 Specifications

General

RFID reader	-
Scanner type	2D
Product color	Black, Silver
Phone function	Yes
International Protection (IP) code	IP68
Display diagonal	5 \
Touch technology	Dual-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Flash memory	32 GB
Internal memory	4 GB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC
Maximum memory card size	128 GB
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	4300 mAh
Number of cores	8
Processor model	650
Processor family	Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Operating system version	6.0
Operating system installed	Android
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
Security algorithms	AES, EAP-TTLS, FIPS 140-2, LEAP, MSCHAPv2, PEAP, TKIP, WEP, WPA, WPA2, WPA2-Enterprise
Rear camera aperture number	2.4
Rear camera resolution (numeric)	13 MP
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	18.6 mm
Width	75.5 mm
Height	155 mm
Weight	249 g
