1 - 4 TC51 User Guide
Setup
Perform this procedure to start using the TC51 for the first time.
1. Install a micro secure digital (SD) card (optional).
2. Install hand strap (optional).
3. Install the battery.
4. Charge the TC51.
5. Power on the TC51.
Installing a microSD Card
The microSD card slot provides secondary non-volatile storage. The slot is located under the battery pack. Refer to
the documentation provided with the card for more information, and follow the manufacturer’s recommendations for
use.
1. Lift the access door.
20 Power Button Turns the display on and off. Press and hold to reset the device, power
off or swap battery.
21 Camera Flash Provides illumination for the camera.
22 Rear Camera Takes photos and videos.
23 Volume Up/Down Button Increase and decrease audio volume (programmable).
24 Scan Button Initiates data capture (programmable).
25 NFC Antenna Provides communication with other NFC-enabled devices.
26 Basic Hand Strap Mount (TC51 Standard) Provides mounting point for Basic Hand Strap
accessory.
Table 1-2 Back View Features (Continued)
Number Item Function
CAUTION Follow proper electrostatic discharge (ESD) precautions to avoid damaging the microSD card. Proper
ESD precautions include, but are not limited to, working on an ESD mat and ensuring that the operator
is properly grounded.
