Accessories 6 - 29
3.5 mm Audio Adapter
The 3.5 mm Audio Adapter plugs into the TC51 and connects to a wired headset with a 3.5 mm plug.
To attach a 3.5 mm headset:
1. Open the headset jack cover.
2. Insert the 3.5 mm Audio Adapter plug into the headset jack.
Figure 6-33 Audio Adapter Installation
3. Connect the 3.5 mm connector plug of the headset into the 3.5 mm Audio Adapter.
Figure 6-34 Connect Headset to 3.5 mm Adapter Cable
NOTE The Audio Adapter is available for the TC51 standard configuration.
