Accessories 6 - 13
Figure 6-9 TC51 Battery Charging
2. Ensure the TC51 is seated properly.
Inserting a TC51 with Rugged Boot into Cradle
Each cradle cup has an insert that must be removed prior to inserting the TC51 with Rugged Boot. Remove the
insert and then insert the TC51 into the cup.
Figure 6-10 Remove Insert from Cup
See the TC51 Touch Computer Integrator Guide for Android Version 6.0.1 for information on
installing the 4-Slot Battery Charger onto the cradle.
