6 - 12 TC51 User Guide
5-Slot Charge Only Cradle
The 5-Slot Charge Only Cradle:
• Provides 5 VDC power for operating the TC51.
• Simultaneously charges up to five TC51s.
Figure 6-8 5-Slot Charge Only Cradle
Charging the TC51
To charge a device:
1. Insert the TC51 into a slot to begin charging.
CAUTION Ensure that you follow the guidelines for battery safety described in Battery Safety Guidelines on page
7-2.
Power LED
TC51 Charging Slot
NOTE If the device has a Rugged Boot, remove the cup insert before inserting the device. See TC51 Touch
Computer Integrator Guide for Android Version 6.0.1 for details.
