Accessories 6 - 25
4. Insert the tab end of the hand strap into the slot on the device.
Figure 6-27 Insert Hand Strap Tab into Slot
5. Feed the tab into the cut in the strap.
Figure 6-28 Feed Tab into Slot
6. Align the hand strap clip with the top cap.
Figure 6-29 Install Hand Strap Clip onto Top Cap
7. Push the clip onto the top cap.
Removal
To remove the Basic Hand Strap Kit:
1. Using thumbs, push the top cap up and rotate over the top of the device.
