A - 2 TC51 User Guide
Voice and Audio Two microphones support with noise cancellation; vibrate alert; speaker;
Bluetooth wireless headset support. High quality speaker phone; PTT headset
support (TC51-Standard only); Cellular circuit switch voice; HD Voice.
Performance Characteristics
CPU Snapdragon 650 64-bit Hexa-Core 1.8GHz ARM Cortex A72, power
optimization
Operating System Android 6.0.1 Marshmallow with Zebra’s Mobility Extensions (Mx) (pre-installed
on both AOSP and GMS options)
Memory Standard: 2 GB RAM/16 GB Flash
Optional: 4 GB RAM/32 GB Flash
Output Power USB - 5 VDC @ 500 mA max
User Environment
Operating Temperature -10°C to 50°C (14°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Charging Temperature 0° C to 40° C (32°F to 104°F)
Relative Humidity Operating: 5 to 95% non-condensing
Drop Specification Multiple 1.2 m (4 ft.) to tile over concrete over operating temperature range.
Multiple 1.5 m (5 ft.) to concrete with Rugged Boot over operating temperature
range.
Tumble 500 0.5 m (1.6 ft.) tumbles; meets and exceeds IEC tumble specifications
Electrostatic Discharge (ESD) +/-15 kVDC air discharge, +/-10 kVDC direct discharge, +/- 10 kVDC indirect
discharge
Vibration 4 g’s PK Sine (5 Hz to 2 kHz); 0.04g2/Hz Random (20 Hz to 2 kHz); 60 minute
duration per axis, 3 axis
Thermal Shock -40°C to 70°C (-40°F to 158°F) rapid transition
Interactive Sensor Technology (IST)
Motion Sensor 3-axis accelerometer Gyro; 3-axis accelerometer
Light Sensor Ambient light sensor to auto adjust display backlight brightness
Proximity Sensor Automatically detects when the user places the handset against head during a
phone call to disable display output and touch input.
Wireless LAN Data and Voice Communications
Radio IEEE 802.11 a/b/g/n/ac/d/h/i/k/r/w; Wi-Fi™ certified; IPv4, IPv6; 2X2 MIMO
Data Rates Supported 5GHz: 802.11a/n/ac - up to 866.7 Mbps
2.4GHz: 802.11b/g/n - up to 144.4 Mbps
Table A-1 TC51 Technical Specifications (Continued)
Item Description
