Printer Setup and Operation
Load Ribbon and Media
64
P1051584-002 8/23/12
5.
6. Wind the ribbon around the core on the ribbon take-up spindle.
Caution • The printhead may be hot and could cause severe burns. Allow the
printhead to cool.
Thread the ribbon under the lower ribbon guide roller (1), under the printhead
assembly
(2), and then over the upper ribbon guide roller (3).
