75
Printer Configuration and Adjustment
Changing Printer Settings
8/23/12 P1051584-002
Print Mode Select a print mode that is compatible with your print engine options.
Accepted values:
• APPLICATOR—The print engine prints a label when
it receives a signal from the applicator.
• TEAR OFF—The print engine prints label formats as
it receives them. The print engine operator can tear off
the printed labels any time after they print.
• STREAM—The print engine prints a batch of labels
with backfeed occurring only at the start and end of
the batch instead of between individual labels. This
setting increases label throughput in batch printing.
• REWIND—The print engine prints without pausing
between labels. The media is wound onto a core after
printing.
Related ZPL command(s):
^MM
SGD command used:
media.printmode
Control panel menu item: PRINT MODE on page 22
Printer web page:
View and Modify Printer Settings > General Setup >
Print
Mode
Applicator
Port
Select the appropriate action for the applicator port, as suggested by the applicator
manufacturer.
Accepted values:
• OFF: The applicator port is off.
• MODE 1: Asserts the ~END_PRINT signal low while
the print engine is moving the label forward.
• MODE 2: Asserts the ~END_PRINT signal high
while the print engine is moving the label forward.
• MODE 3: Asserts the ~END_PRINT signal low for
20
milliseconds when a label has been completed and
positioned. Not asserted during continuous printing
modes.
• MODE 4: Asserts the ~END_PRINT signal high for
20 milliseconds when a label has been completed and
positioned. Not asserted during continuous printing
modes.
Related ZPL command(s):
^JJ
SGD command used:
device.applicator.end_print
Control panel menu item: APPLICATOR PORT on page 22
Printer web page:
View and Modify Printer Settings > Advanced Setup >
Applicator
Table 5 • Print Settings (Continued)
