RO=çÑ=NPQ fåëíêìÅíáçå=j~åì~ä=`êçëëÄÉ~ã=PQM=ÉåMOE`lo F
PK=aÉëÅêáéíáçå
qÉÅÜåáÅ~ä=Ç~í~
3.5.2. Installation requirements
Location requirements
Installation site Exclusively inside buildings
Room size Min 3.5 m x 5.0 m x 2.3 m (W x D x H)
Service area Min 1.0 m at each side
Installation category II
Exhaust line An exhaust line is required to remove the
wate gas of the pre-vacuum pump and to
transmit it to the outside.
Electrical supplies
Nominal AC voltage 208 V - 230 V (±10%), 1/N (L2) / PE
Protection class I
Nominal frequency 50 - 60 Hz
Power consumption Max. 3.7 kVA, dependent on upgrade stage
and installed optional accessories
Current input Max. 16 A
Circuit breaker 25 A, switch off behaviour K on installation site
Moreover, it is recommended to protect the complete room by installing a
power switch next to the door of the room.
Ampere interrupting
capacity AIC
At least 10000 A rms
Protective ground The workstation must be connected via a separate protective ground.
An exclusive grounding connection to earth must be provided, i. e. the
grounding terminal must not be common to other electrical equipment.
A grounding wire AWG10 (5 m long) is delivered with the workstation.
Cross section
> 4 mm
2
Ground resistance
< 0.1
Cooling water supply
Water flow rate Approx. 2 l/min
Input pressure 0.3 - 0.35 MPa (3 - 3.5 bar)
Water temperature 20 - 22°C
Stability 0.5°C/10 min
