Zenith Z5 - Getting Started with Zenith Z5

User Manual ver.1.03
9
Chapter 2. Getting started with Zenith Z5
2.1. Specification
Z5 Base Unit specification
General Specification
Category
Specifications
CPU
Octa Core Processor 2.0 GHz
Operating System
Android 9
System Memory
3G / Internal 32G **
External Memory
Micro SD Card
LCD
8.0 inch FHD (1920 x 1200)
Input Devices
Capacitive Touch Screen, 3 Hard Keys (Power, Volume +, Volume -)
Camera
8 megapixel auto-focus with LED flash
Sound
Loud Speaker 1 microphone; 3.5 pi standard audio jack
Rechargeable Battery
Li-ion 3.8V 3200 mAh
Operating voltage
DC 9 ~ 30V
Sensors
Ambient Light, Proximity, Gyroscope, Accelerometer
Dimension
225 x 136 x 33 mm
Weight
800g
Connectivity
External port
USB 1ea, USB C 1 ea.
Network
RJ45 Ethernet, Wi-Fi 802.11 a/b/g/n, Bluetooth 4.2
Supported Vehicle Communication Protocols
CAN (High speed, Low speed, Single), ISO-9141, ISO-9141-CARB, KWP-2000,
SAE-J1708, SAE-J1587, J1850(PWM/VPW), Melco Pull-Down
** Half (16GB) of Z5’s internal memory (32GB) is allocated for Z5 diagnostic software and future
updates. Therefore, the actual available memory size may be less than the capacity displayed in the
storage under setting.
